The closing power mentioned above refers to the use of one self-closing hinge per door leaf (900 x 2100 mm).
The self-closing hinge has to be used only in combination with the given hinges and has to be installed at half the height of the door leaf, approximately at the same height of the lock (magnetic lock recommended).
Alternatively, the routing can be carried out with a cutter diameter of 14,0 mm and a collar ring diameter of 25,0 mm.
| Weight, kg | 0.450000 |
|---|---|
| Country of origin | Italy |
| Model Name | AN 107 3D C60 |
| Brand | ANSELMI |
| Material | Zamak, Steel |
| Hinge type | Concealed hinges |
| Door material | Wooden doors |
| Fire-resistance | Not suitable for fire-resistant doors |
| Quantity | 1 |
| Manufacturer warranty | 24 months |
| Package sizes, mm | 150 x 100 x 40 |
