No Attachments!
Closure type: PZ 72mm
Backset: 65mm
Panic functions:
B or B reverse
C or C reverse
D or D reverse
E
Forehead - stainless steel
Forehead dimensions:
20 mm for rebated doors
24 mm for non-rebated doors
Walnut: 9mm
Designed for fire and smoke-tight doors
Certificate according to: EN 179, EN 1125, DIN 18250, EN 12209
| Weight, kg | 1.100000 |
|---|---|
| Country of origin | Germany |
| Finish | Satin stainless steel |
| Model Name | GBS 92 |
| Material | Stainless Steel |
| Lock type | Single-point locks |
| Lock operation type | Mechanical |
| Purpose | For exterior doors |
| Door material | Steel and wooden doors |
| Fire-resistance | For fire-resistance doors |
| Hardware for escape doors | Complies with EN179 and EN1125 |
| Brand | ECO SCHULTE |
| Manufacturer warranty | 24 months |
| Package sizes, mm | 240 x 100 x 25 |
