- New packaging for easy removal
- Packed as handle sets
- DIN left / DIN right useable
- Return spring, system A
- All current handle shapes available
- Maintenance-free bearing
- Fixable bearing
- 45° operating angle
- ECO CLICK quick installation
- EN 1906 utilization class 3 certified
- Preassembled, fixed positioning studs
- Stable M5 screwing
- High fixed pin connection through grooved square spindle
- Standard door thickness 38 - 45 mm (Additional pin lengths on request)
- Also available in aluminum
- 55 mm rose diameter (Suitable for object and fire protection handles)
| Weight, kg | 0.650000 |
|---|---|
| Country of origin | Germany |
| Model Name | SGL D-310 |
| Brand | ECO SCHULTE |
| Finish | Satin stainless steel |
| Material | Stainless Steel |
| Door type | For External / Internal |
| Door material | Steel and wooden doors |
| Handle type | Handles on round rosette |
| Mounting standard | DIN standard |
| Fire-resistance | Not suitable for fire-resistant doors |
| Handle Grade - EN1906 | Grade 3 |
| Hardware for escape doors | Not suitable |
| Quantity | 1 |
| Package sizes, mm | 190 x 160 x 60 |
| Manufacturer warranty | 24 months |
